VETRO-CONV-SDI-HDMI
Rugged SDI to HDMI/DVI video converter
The VETRO-CONV-SDI-HDMI is part of AMP’s rugged intelligent video converter family designed for vehicle and mobile applications. The VETRO-CONV-SDI-HDMI seamlessly converts SDI video signals to high definition HDMI/DVI video ensuring reliable performance for Military, Communications, Transportation, and Energy industries.
This VETRO-CONV family are ideal for a wide range of critical requirements, including the integration of new sensors onto existing platforms, vehicle or platform upgrade and retrofit projects, and expanding the operational lifespan of legacy systems. It provides the seamless, automatic video conversion necessary for enabling these mission-critical tasks.
The VETRO-CONV-SDI-HDMI features D38999 connectors and is vehicle-ready with no user intervention. Built tough with conduction-cooled, watertight, IP67-rated enclosure and integrated MIL-STD-1275E power conditioning, the VETRO-CONV-SDI-HDMI delivers power-transient hardened operation for dependable performance in harsh environments.
NB: Preliminary Information Subject To Change
Highlights
- Vehicle ready, rugged video converter
- SMPTE compliant SDI input
- HDMI / DVI video output
- Military grade, rugged IP67 enclosure
- Sealed, MIL-D38999 connectors for secure cabling
- Power transient hardened
- Designed for demanding applications in harsh environments
Applications
-
Integration of new sensors
-
Situational awareness
-
Lifespan extension projects
-
Vehicle surveillance systems
-
Platform Upgrades and Retrofit
-
Security systems for critical infrastructure
-
Mobile command centers
Supported Platforms
n/a
Digital Video Input
- SMPTE compliant SDI input
- SMPTE 259M standard definition (NTSC and PAL)
- SMPTE 292M HD-SDI High definition (up to 1080p30)
- SMPTE 424M 3G-SDI (up to 1080p60)
- 75 Ohm input
Video Output
- DVI Compliant HDMI output
Video Conversion
- Intelligent solution – no configuration required.
Latency
- Latency < 1 frame time
- Zero buffer process
- No video data persistence
Environmental
- Operating temp –20˚C to +60˚C
- IP67 dust-proof, water immersion to 1m
- Passively cooled, fanless enclosure
Power
- 12-31V DC Input range
- 28V DC Nominal input voltage
- Hardened against power transients
- Reverse polarity protection
- EMI hardened for immunity and emissions
- Military vehicle class power conditioning conforming to MIL-STD-1275E
Mechanical
- Milled from solid Aluminium Alloy block
- Size: 120 x 120 x 40 mm (4.7 x 4.7 x 1.6 inch) LWH
- Sealed IP67 rugged MIL-D38999 Connectors
